| MOQ: | 1 |
| Price: | $500—1000 |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union |
| System Model | 1to2 | 1to2 | 1to4 |
|---|---|---|---|
| Component Parameters | |||
| Component Model | DHT-M56X10 FS(BB) | DHN-I48Z16/DG(BW) | DHN-I48Z16/DG(BW) |
| Standard Dimensions | 1766x1132x32mm | 1762x1134x35mm | 1762x1134x35mm |
| Weight | 22.5kg | 24.3kg | 24.3kg |
| Electrical Performance Parameters (STC) | |||
| Maximum Power (Pmax) | 420W | 450W | 450W |
| Maximum Power Point Voltage (Vmpp) | 97.3V | 61.2V | 61.2V |
| Maximum Power Point Current (Impp) | 4.32A | 7.35A | 7.35A |
| Open Circuit Voltage (Voc) | 115.4V | 72.0V | 72.0V |
| Short Circuit Current (Isc) | 4.56A | 7.82A | 7.82A |
| Power per Square Meter (W/m²) | 210W | 225W | 225W |
| Safety Parameters | |||
| Maximum Static Load on Front | 5400Pa | 5400Pa | 5400Pa |
| Maximum Static Load on Rear | 2400Pa | 2400Pa | 2400Pa |
| Protection Level | IP68 | IP68 | IP68 |
| Temperature Coefficient | |||
| Temperature Coefficient (Isc) | 0.05%/℃ | 0.046%/℃ | 0.046%/℃ |
| Temperature Coefficient (Voc) | -0.31%/℃ | -0.25%/℃ | -0.25%/℃ |
| Temperature Coefficient (Pmpp) | -0.35%/℃ | -0.29%/℃ | -0.29%/℃ |
| Micro-Inverter Parameters | |||
| Micro-Inverter Model | DHN-SU920D-G0 | DHN-SU1KCD-G1 | DHN-SU2KCD-G1 |
| Maximum Input Voltage | 420V | 420V | 470V |
| MPPT Voltage Range | 120~360V | 70~340V | 70-400V |
| Start-up Voltage | 50V | 50V | 50V |
| Maximum Input Current | 4.2A | 7.5A | 7.5A |
| Maximum Output Active Power | 920W | 1000W | 2000W |
| Maximum Efficiency | 0.972 | 0.9719 | 0.976 |
| Operating Temperature Range | -40℃~+65℃ | -40℃~+70℃ | -40℃~+70℃ |
| Communication Method | WIFI/PLC | WIFI/PLC | WIFI/PLC |
| Weight | 2.0kg | 3.5kg | 3.7kg |
| Dimensions | 412*99*43mm | 420*112*44mm | 420*112*44mm |
| Protection Level | IP65 | IP67 | IP67 |
