| MOQ: | 1 |
| Price: | $750-950 |
| Payment Terms: | L/C,T/T,Western Union,D/A,D/P |
| Battery Type | Lead-acid/Li-Ion |
| Battery Voltage Range (V) | 40~60 |
| Max. Charging Current (A) | 70 |
| Max. Discharging Current (A) | 70 |
| Charging Strategy for Li-ion Battery | Self-adaption to BMS |
| Number of Battery Input | 1 |
| Max. PV Input Power (W) | 4800 |
| Max. PV Input Voltage (V) | 500 |
| Start-up Voltage (V) | 120 |
| MPPT Voltage Range (V) | 120~425 |
| Rated PV Input Voltage (V) | 370 |
| Max Operating PV Input Current (A) | 20 |
| Max. Input Short-Circuit Current (A) | 23 |
| No. of MPP Tracker / No. of Strings MPP Tracker | 1+1 |
| Rated AC Input/Output Active Power (W) | 3000 |
| Max. AC Input/Output Apparent Power (VA)* | 3300 |
| Rated AC Input/Output Current (A) | 13.6/13 |
| Max. AC Input/Output Current (A)* | 15/14.3 |
| Max. Continuous AC Passthrough (grid to load) (A) | 27 |
| Peak Power (off-grid) (W) | 2 times of rated power for 10s |
| Power Factor Adjustment Range | 0.8 leading to 0.8 lagging |
| Rated Input/Output Voltage/Range (V) | 220/230 0.85Un-1.1Un |
| Rated Input/Output Grid Frequency/Range (Hz) | 50/45-55, 60/55-65 |
| Grid Connection Form | L+N+PE |
| Total Current Harmonic Distortion THDi | <2% (of nominal power) |
| DC Injection Current | <0.5% In |
| Max. Efficiency | 97.60% |
| Euro Efficiency | 96.50% |
| MPPT Efficiency | 99% |
| Communication Interface | RS485/CAN |
| Monitor Mode | WIFI |
| Operating Temperature Range (°C) | -40 to +60 |
| Permissible Ambient Humidity | 0-100% |
| Permissible Altitude (m) | 3000 |
| Ingress Protection (IP) Rating | IP65 |
| Inverter Topology | Non-Isolated |
| Over Voltage Category | OVC II (DC), OVC III (AC) |
| Cabinet Size (W×H×D mm) | 330×563×223 |
| Weight (kg) | 23.7 |
| Type of Cooling | Natural cooling |
| Warranty | 5 Years / 10 Years |
