| MOQ: | 1 |
| Price: | $1800-2000 |
| Payment Terms: | D/A,L/C,D/P,T/T,Western Union |
CE RoHS Solar Battery Home Backup 10.44kWh ESS Solar Battery
serving as a wall-mounted home energy hub, this all-in-one unit scales from 10.44kWh and integrates the inverter and PV input. It optimizes solar self-consumption for homes, secures power for villas or home offices, and switches to backup within 20ms during grid failures.
● Cost-Effective & Durable
Employing Lithium Iron Phosphate (LiFePO4) technology, cycle life up to 6000 cycles, supports daily use for over 15 years, reducing long-term operational costs.
● Single MPPT PV Input
Supports up to 5kW PV input, MPPT range 150-500V, compatible with most PV modules.
● Adjustable Power Factor
Power factor adjustable from 0.8 leading to 0.8 lagging, compatible with various grid requirements.
● High Efficiency&Low THDi
Output THDi＜3%, high power quality, safe for sensitive electronics.
● Fast Grid Transfer
Grid transfer time 20ms, ensuring uninterrupted operation of important appliances.
● Smart Communication
Supports CAN/RS485 communication for integration with energy management systems, enabling remote monitoring and O&M to improve management efficiency.
● Modern Design
Wall-mounted design, saving floor space and reducing cleaning.
| Battery Data | |
| Model | W5-10K |
| Cell Chemistry | LFP/ 102Ah |
| Rated Energy (kWh) | 10.44kWh |
| Pack Configuration | 2P16S |
| Rated Voltage (V) | 51.2V |
| Operating Voltage Range (VDC) | 44.8-57.6VDC |
| PV Input | |
| Max. PV Input Power (W) | 5,000W |
| Max. PV Input Voltage (V) | 500V |
| MPPT Voltage Range (V) | 150-500V |
| Start-up Voltage (V) | 370V |
| Number of MPPTs (Pcs) | 1 |
| Max. PV Input Current per MPPT (A) | 60A |
| AC Input & Output | |
| Rated Input/ Output Power (W) | 5,000W |
| Rated Input/ Output Voltage (V) | 220V/ 230V/ 240V (Adjustable) |
| Rated AC Frequency (Hz) | 50/ 60Hz |
| Max. Output Current (A) | 22A |
| Total Harmonic Distortion (THDi) | <3% |
| Power Factor | 0.8 Leading to 0.8 Lagging |
| Grid Transfer Time (ms) | 20ms |
| Grid Connection | Single Phase |
| General Data | |
| Dimensions (W*D*H) (mm) | 600x163x1,005 |
| Weight (kg) | 108 |
| Altitude (m) | 4,000m (Derating above 1,000m) |
| Display | LCD Display |
| Safety Protection | High/Under Voltage Protection, Short Circuit Protection, Overload Protection. |
| BMS Communication | CAN/RS485 |
| IP Rating | IP21 |
| Operating Temperature (℃) | -15~60℃ (Battery: 0~40℃) |
| Relative Humidity | 20%~95% (No Condensing) |
| Cycle Life | 6,000 Cycles |
| Installation Method | Wall-Mounted |
| Certifications | CE, RoHS, UN38.3 |
