Low No-Load Loss – Lower than high-frequency machines with the same power rate Minimizes standby power consumption, reducing energy waste and improving overall system efficiency compared to conventional high-frequency inverters.
Pure Sine Wave Output – Suitable for different loads Delivers clean, stable power that safely operates sensitive electronics, inductive loads such as refrigerators and air conditioners, and a wide range of household appliances.
Adjustable Parameters – Multiple parameters can be adjusted according to user needs Allows flexible configuration of charging voltage, battery type, and operating modes to match specific application requirements and system setups.
Slim Body – Convenient installation and transportation Compact and lightweight design simplifies handling during installation and makes it easy to transport, saving space and reducing installation complexity.
Battery Reverse Connection Protection with Fuse-Free Switch – Safer installation Prevents damage caused by incorrect battery polarity connections, ensuring a safer installation process without the need for traditional fuses.
Built-in MPPT Solar Controller Integrated maximum power point tracking technology optimizes solar energy harvest by continuously adjusting to the maximum power output of PV panels under varying conditions.
High Output Voltage Precision – Take care of your appliances Maintains stable and accurate output voltage, protecting connected appliances from voltage fluctuations and ensuring reliable long-term operation.
WiFi / Lithium Battery BMS Communication Support Enables remote monitoring and control via wireless networks, and allows seamless communication with lithium batteries for optimized charging performance and battery health management.

Application Scenarios

Small Household PV Systems Designed for residential solar installations to maximize on-site self-consumption and store excess solar energy for later use.
Remote Areas with Limited Grid Access Delivers reliable, stable power to household appliances and lighting in locations where grid electricity is unavailable or unreliable.
Emergency Backup Power Provides dependable backup power for homes and small shops, ensuring essential equipment stays running during unexpected grid outages.

Model		CH—ED3024EMH
AC Input	AC Input Voltage	220VAC (Standard) / 110VAC (Custom)
	Input Voltage Range	90~280VAC±3V(Normal Mode) 170~280VAC±3V(UPS Mode)
	Input Frequency	50/60Hz±5%
	Rated Output Power (Battery Mode)	3000W
Output	Rated Output Power (PV Mode)	3000W
	Output Voltage	220/230/240VAC±5%
	Output Frequency	50/60Hz±0.1%
	Output Wave	Pure Sine Wave
	Transfer Time	≤10ms(UPS Mode)/≤20ms(INV Mode)
	Peak Power	6000VA
	Overload Ability	Battery Mode:1ls@105%-150% Load 2s@150%-200% Load 400ms@200% Load
Grid-connected Operation	Output Voltage
	Grid-Tied Voltage Range
	Grid-Tied Frequency Range
	Rated Output Curren
	Power Factor Range
	Peak Efficiency (DC/AC)
Battery	Rated Voltage	24Vdc
	Constant Charging Voltage (Adjustable)	28.2Vdc
	Float Charging Voltage (Adjustable)	27Vdc
Charger	PV Charging Mode	MPPT
	Max PV Input Power	3000W
	MPPT Input Voltage Range	30-500Vdc
	Optimal VMP Range	300-400Vdc
	Max PV Input Voltage	500Vdc
	Max PV Input Current	13A
	Max PV Charging Current	100A
	Max AC Charging Current	60A
	Max Charging Current	100A
Display	LCD Interface	can display operating mode/load/input/output
Interface	RS232	Baud Rate 2400
	Expansion Slot Communication Interface	Lithium Battery BMS Communication Card, WIFI/Pitch2.54mm
	Parallel Interface / Parallel Port	Not support Parallel
Ambient Temperature	Operating Temperature	-10°C-50°C
	Operating Humidity	-10°C-60°C
	Storage Temperature	20%-90% Non Condensing
	Noise	≤50dB
