Wide PV Input Voltage Range – Supports 60–500VDC input, compatible with various solar panel configurations for enhanced application adaptability
External WiFi Module – Enables remote monitoring and control through wireless networks
High Conversion Efficiency – Delivers up to 98% peak efficiency with minimal power loss, optimizing photovoltaic system performance
Multiple Battery Type Compatibility – Supports lithium battery BMS communication, flexible energy storage system configurations to meet diverse application requirements
Sturdy & Compact Structure – Lightweight, slim body design for easy installation and space efficiency
Pure Sine Wave Output – 6200W rated power, 12400VA peak power, suitable for air conditioners, pumps, refrigerators, and other inductive loads

Product Features

Low No-Load Loss: Lower than high-frequency machines with the same power rate
Pure Sine Wave Output: Suitable for different loads
Adjustable Parameters: Multiple parameters can be adjusted according to user needs
Slim Body: Convenient installation and transportation
Battery Reverse Connection Protection with Fuse-Free Switch: Safer installation
Built-in MPPT Solar Controller
High Output Voltage Precision: Take care of your appliances
WiFi / Lithium Battery BMS Communication Support

Model		CH—ED6248EMH
AC Input	AC Input Voltage	220VAC (Standard) / 110VAC (Custom)
	Input Voltage Range	90~280VAC±3V(Normal Mode) 170~280VAC±3V(UPS Mode)
	Input Frequency	50/60Hz±5%
	Rated Output Power (Battery Mode)	6200W
Output	Rated Output Power (PV Mode)	6200W
	Output Voltage	220/230/240VAC±5%
	Output Frequency	50/60Hz±0.1%
	Output Wave	Pure Sine Wave
	Transfer Time	≤10ms(UPS Mode)/≤20ms(INV Mode)
	Peak Power	12400VA
	Overload Ability	Battery Mode:1ls@105%-150% Load 2s@150%-200% Load 400ms@200% Load
Grid-connected Operation	Output Voltage	220/23024VVAC
	Grid-Tied Voltage Range	170-265VAC
	Grid-Tied Frequency Range	49-51±Hz/59-61±Hz
	Rated Output Curren	26.9A
	Power Factor Range	>0.99
	Peak Efficiency (DC/AC)	98%
Battery	Rated Voltage	48Vdc
	Constant Charging Voltage (Adjustable)	56.4Vdc
	Float Charging Voltage (Adjustable)	54Vdc
Charger	PV Charging Mode	MPPT
	Max PV Input Power	6200W
	MPPT Input Voltage Range	60-500Vdc
	Optimal VMP Range	400-400Vdc
	Max PV Input Voltage	500Vdc
	Max PV Input Current	18A
	Max PV Charging Current	120A
	Max AC Charging Current	100A
	Max Charging Current	120A
Display	LCD Interface	Can display operating mode/load/input/output
Interface	RS232	Baud Rate 2400
	Expansion Slot Communication Interface	Lithium Battery BMS Communication Card, WIFI/Pitch2.54mm
	Parallel Interface / Parallel Port	Not support Parallel
Ambient Temperature	Operating Temperature	-10°C-50°C
	Operating Humidity	-10°C-60°C
	Storage Temperature	20%-90% Non Condensing
	Noise	≤50dB
