Wide PV Input Voltage Range - Supports 60-500V input, compatible with various solar panel configurations for enhanced application adaptability
External WiFi Module - Enables remote monitoring and control through wireless networks
High Conversion Efficiency - Delivers superior energy conversion with minimal power loss, optimizing photovoltaic system performance
Multiple Battery Type Compatibility - Flexible energy storage system configurations to meet diverse application requirements
Sturdy & Compact Structure - Lightweight, durable casing design for easy installation and space efficiency

Application Scenarios

Small household photovoltaic systems for on-site self-consumption and surplus power storage
Remote area power solutions for villages and mountainous regions with limited grid access
Emergency backup power supply for households and small commercial establishments

Additional Advantages

Factory Direct Supply - Direct manufacturing and order processing for stable, efficient supply chain
Flexible Production - Support for small-batch trial orders with minimum order quantity of 1 unit
Customization Service - Customizable voltage, interfaces, and other parameters to meet specific requirements

Technical Specifications

Model	CH-ED6248EMH
AC Input Voltage	220VAC (Normal) / 110VAC (Customize)
Input Voltage Range	90-280VAC±3V (Normal Mode) 170-280VAC±3V (UPS Mode)
Input Frequency	50/60Hz±5%
Rated Power	6200W
Output Voltage	220/230/240VAC±5%
Output Frequency	50/60Hz±0.1%
Output Wave	Pure Sine Wave
Transfer Time	≤10ms (UPS) / ≤20ms (INV)
Peak Power	12400VA
Grid Voltage Range	170-265VAC
Power Factor Range	>0.99
Peak Efficiency (DC/AC)	98%
Battery Rated Voltage	48Vdc
Max PV Input Power	6200W
MPPT Input Voltage Range	60-500Vdc
Max PV Input Voltage	500Vdc
Max PV Input Current	18A
Operating Temperature	-10°C to 50°C
Noise Level	≤50dB
